VASAGLE ULTV556K01 TV Stand Instruction Manual

Fiosrachadh Sàbhailteachd Cudromach

Leugh na stiùiridhean gu lèir gu faiceallach mus cuir thu ri chèile agus mus cleachd thu iad. Cùm an leabhar-làimhe seo airson fiosrachadh san àm ri teachd.

Do not exceed the maximum weight capacity specified for this TV stand. Overloading can cause injury or damage.
Dèan cinnteach gu bheil na sgriothan agus na ceanglaichean uile air an teannachadh gu tèarainte mus cleachd thu iad. Thoir sùil orra bho àm gu àm agus teannaich a-rithist ma tha sin riatanach.
Cùm pàirtean beaga air falbh bho chloinn fhad ’s a tha iad gan cur ri chèile gus casg a chuir air cunnart tachdadh.
Cruinnich an aonad air uachdar bog, glan gus casg a chur air sgrìoban.
Mura h-eil pàirtean sam bith a dhìth no millte, na lean air adhart leis an t-seanadh. Cuir fios gu taic luchd-cleachdaidh sa bhad.
Always use the anti-tip kit provided to secure the TV stand to a wall, especially in homes with children or pets, to prevent tipping accidents.

Susbaint pacaid

Verify that all components are present before beginning assembly. If any parts are missing, please contact customer service.

Ìomhaigh: Spreadhadh view of the VASAGLE TV Stand showing all individual parts, including wooden panels, metal legs, screws, and assembly tools. This image helps users identify and count all components before starting assembly.

Liosta bathar-cruaidh:

A: M6x30mm Screws (x12)
B: M4x15mm Screws (x8)
C: Dowels (x10)
D: Allen Wrench (x1)
E: Anti-tip Kit (x1 set)

Panel List:

Pannal as àirde (x1)
Pannal Ìosal (x1)
Pannalan Taobh (x2)
Shelf Panels (x2)
Pannal Cùil (x1)
Casan (x4)

Suidheachadh agus Seanadh

Follow these steps carefully to assemble your VASAGLE TV Stand.

Ceum 1: Ceangail na casan ris a’ phannal ìosal. Place the bottom panel (2) upside down on a soft surface. Secure the four legs (6) to the designated corners using M6x30mm screws (A). Tighten with the Allen wrench (D).
Description: Illustration showing the bottom panel with pre-drilled holes and the four legs being attached with screws and an Allen wrench.
Step 2: Assemble Side Panels. Insert dowels (C) into the pre-drilled holes on the side panels (3). Attach the side panels to the bottom panel, ensuring the dowels align. Secure with M6x30mm screws (A) from the underside of the bottom panel.
Description: Diagram illustrating the connection of side panels to the bottom panel using dowels and screws, highlighting proper alignment.
Step 3: Install Shelf Panels. Slide the shelf panels (4) into the grooves on the side panels. Ensure they are level and fully seated. Secure them using M4x15mm screws (B) through the pre-drilled holes on the side panels.
Description: Visual guide showing the shelf panels being inserted into the side panel grooves and secured with screws.
Step 4: Attach Top Panel. Place the top panel (1) onto the assembled structure, aligning the dowels and screw holes. Secure the top panel to the side panels using M6x30mm screws (A).
Description: Image depicting the top panel being placed and fastened to the rest of the TV stand frame.
Step 5: Install Back Panel. Position the back panel (5) against the rear of the unit. Secure it using M4x15mm screws (B) into the designated holes along the edges.
Description: Illustration showing the back panel being attached to the rear of the TV stand with screws.
Step 6: Attach Anti-Tip Kit. Locate a suitable wall stud. Attach one bracket of the anti-tip kit (E) to the back of the TV stand and the other to the wall using the provided hardware. Connect them with the strap. This step is crucial for safety.
Description: Diagram demonstrating how to properly install the anti-tip kit, showing the bracket attachment to both the TV stand and the wall.

Stiùireadh Obrachaidh

Proper use ensures the longevity and safety of your TV stand.

Suidheachadh: Position the TV stand on a flat, level surface to prevent wobbling and ensure stability.
Sgaoileadh cuideam: Distribute weight evenly across the top and shelves. Avoid placing heavy items on one side only.
Riaghladh càbaill: Utilize any built-in cable management features to keep wires tidy and prevent tripping hazards.
Fionnarachadh: Ensure adequate airflow around electronic devices placed on the stand to prevent overheating.

Cùram agus cumail suas

Regular maintenance will help preserve the appearance and structural integrity of your TV stand.

Glanadh: Sguab an uachdar le bog, damp clò. Seachain ceimigean cruaidh no innealan-glanaidh sgrìobach, a dh’ fhaodadh milleadh a dhèanamh air a’ chrìochnachadh.
Dòrtadh: Glan suas dòrtadh sa bhad gus casg a chur air staining no milleadh uisge.
Solas na grèine: Seachain nochdadh fad-ùine do sholas dìreach na grèine, a dh’ fhaodadh crìonadh no dath a dhèanamh air a’ chraiceann.
Teòthachd agus Taiseachd: Maintain a stable room temperature and humidity level to prevent warping or cracking of wood components.
Sgrùdadh fastener: Thoir sùil bho àm gu àm air na sgriothan is na ceanglaichean uile gus dèanamh cinnteach gu bheil iad fhathast teann. Teannaich a-rithist ma tha sin riatanach.

Fuasgladh thrioblaidean

Thoir sùil air an earrann seo airson fuasglaidhean air cùisean cumanta.

Trioblaid	Adhbhar a dh’fhaodadh a bhith ann	Fuasgladh
Tha an seasamh crathach/neo-sheasmhach.	Ceanglaichean sgaoilte; làr neo-chothromach; cruinneachadh ceàrr.	Ensure all screws are tightened. Move to a level surface or use shims under legs. Review ceumannan cruinneachaidh.
Chan eil pàirtean a’ freagairt ri chèile.	Incorrect orientation of parts; wrong parts used.	Double-check part numbers and orientation against the assembly diagrams. Do not force parts.
Missing hardware/parts.	Mearachd pacaidh.	Contact customer support with your model number and a list of missing items.

Sònrachaidhean

Modail: ULTV556K01
Stuth: Fiodh Innleadaichte, Stàilinn
Meudan iomlan: Approximately 59.1" L x 15.7" W x 19.7" H (150 cm x 40 cm x 50 cm)
Max. Static Load Capacity of Top: 110 lbs (50 kg)
Max. Static Load Capacity of Each Shelf: 33 lbs (15 kg)
Meud Tbh a thathar a’ moladh: Suas gu 65 òirleach

Barantas agus Taic

VASAGLE products are designed for quality and durability. This product comes with a standard manufacturer's warranty against defects in materials and workmanship.

Ùine barantais: Please refer to your purchase documentation or the official VASAGLE weblàrach-lìn airson teirmichean agus fad barantais sònraichte.
Pròiseas tagraidh: To make a warranty claim, please retain your proof of purchase and contact VASAGLE customer support.
Taic teachdaiche: For assembly assistance, missing parts, or any other inquiries, please visit the official VASAGLE weblàrach-lìn no cuir fios chun sgioba seirbheis teachdaiche aca gu dìreach.
Goireasan air-loidhne: Additional support, FAQs, and product information may be available on the VASAGLE official weblàrach: www.vasagle.com
