Fiosrachadh Sàbhailteachd Cudromach
Leugh a h-uile stiùireadh mus cleachd thu an inneal seo gus cunnart teine, clisgeadh dealain no leòn a lùghdachadh. Cùm an leabhar-làimhe seo airson fiosrachadh san àm ri teachd.
- Sàbhailteachd dealain: This appliance must be properly grounded. Ensure the power outlet is correctly installed and compatible with the appliance's voltage (115 Volts) and plug type (Type A - 2 pin North American). Do not use extension cords or ungrounded adapters.
- Reòthadair lasaichte: This appliance uses R-134a or R-600a refrigerant. Handle with care. Do not damage the refrigerant circuit. Servicing should only be performed by authorized personnel.
- Fionnarachadh: Dèan cinnteach gu bheil fionnarachadh iomchaidh timcheall an inneil. Na cuir bacadh air fosglaidhean fionnarachaidh sam bith.
- Sàbhailteachd Cloinne: Do not allow children to play with, operate, or crawl inside the appliance. Proper disposal of old appliances is crucial to prevent child entrapment.
- Moladh 65 Rabhadh: Faodaidh an toradh seo do nochdadh gu ceimigean a’ toirt a-steach Di (2-ethylhexyl) phthalate (DEHP), a tha fios aig Stàit California a dh’ adhbhraicheas aillse agus lochdan breith no cron gintinn eile. Airson tuilleadh fiosrachaidh rachaibh gu www.P65Warnings.ca.gov.
Stàladh agus stàladh
Proper installation is essential for optimal performance and safety.
A' dì-phapadh
- Thoir air falbh a h-uile stuth pacaidh, a’ gabhail a-steach foam agus teip.
- Inspect the appliance for any damage. Report any damage to the retailer immediately.
- Cùm stuthan pacaidh airson còmhdhail no seirbheis san àm ri teachd.
Suidheachadh agus suidheachadh
This unit is designed for built-in installation under a counter. Ensure the chosen location meets the following criteria:
- Meudan: The appliance dimensions are 23.4"D x 22.6"W x 33.9"H. Ensure the cabinet opening provides sufficient clearance.
- Fionnarachadh: Do not obstruct the front ventilation grille. Adequate airflow is critical for cooling efficiency.
- Uachdar: Place the unit on a flat, level, and sturdy surface capable of supporting its weight (approximately 106 pounds).
- Àrainneachd: Avoid direct sunlight or heat sources. Maintain a stable ambient temperature between 60°F and 90°F (16°C and 32°C).
Ìre an inneal
The appliance features adjustable leveling feet. Use a level to ensure the unit is perfectly level before operation. Adjust the feet by turning them clockwise to raise or counter-clockwise to lower.
Image: Adjustable leveling feet at the base of the cooler.
Ceangal dealain
Connect the appliance to a dedicated, properly grounded 115 Volt, 60 Hz AC outlet. Do not use a power strip or extension cord.
Dealbhadh pannal deiseil
This cooler features a panel-ready design, allowing you to integrate custom cabinet panels (not included) to match your kitchen decor. Refer to the detailed installation guide for panel attachment instructions.
Image: The cooler integrated into kitchen cabinetry, demonstrating the panel-ready design. Custom panels are not included.
Stiùireadh Obrachaidh
This dual-zone cooler allows for precise temperature control for both wine and beverages.
Pannal Smachd
The digital control panel is located at the top center of the interior. It allows you to set and monitor temperatures for both zones.
Image: Digital control panel with temperature display and adjustment buttons.
Sònaichean Teòthachd
- Left Zone (Beverage): Temperature range 36°F - 43°F (2°C - 6°C). This zone has a capacity of 2.1 Cu. Ft. and is ideal for chilling various beverages.
- Right Zone (Wine): Temperature range 41°F - 68°F (5°C - 20°C). This zone can store up to 20 standard wine bottles on wooden shelves.
Image: Visual representation of the dual temperature zones and their respective ranges.
Ag atharrachadh teòthachd
Use the '+' and '-' buttons on the control panel to adjust the desired temperature for each zone. The display will show the set temperature. Allow several hours for the unit to reach the new temperature setting.
Solais a-staigh
The cooler features LED interior lights. Use the light button on the control panel to turn the lights on or off.
Image: Interior of the cooler with LED lighting, showcasing stored items.
Glasadh an dorais
The appliance is equipped with a key lock for security. Insert the key into the lock located at the bottom of the door and turn to lock or unlock.
Image: Key for the door lock mechanism.
Cumail suas
Regular maintenance ensures the longevity and efficient operation of your cooler.
Dì-reothadh fèin-ghluasadach
This appliance features an automatic defrost system, eliminating the need for manual defrosting. Frost will melt and evaporate automatically.
A 'glanadh an taobh a-staigh
- Cuir a-mach an cumhachd mus tèid a ghlanadh.
- Clean the interior with a soft cloth, warm water, and a mild, non-abrasive detergent.
- Do not use harsh chemicals, abrasive cleaners, or scouring pads, as these can damage surfaces.
- Tiormaich gu mionaideach an dèidh glanadh.
A 'glanadh an taobh a-muigh
- Wipe the exterior surfaces with a soft cloth and a mild detergent.
- For glass doors, use a glass cleaner.
- Ensure the ventilation grille at the front is kept clear of dust and debris for proper airflow.
Sgeilpichean fiodha
Faodar na sgeilpichean fiodha a thoirt air falbh airson an glanadh. Sguab iad le ad.amp cloth and dry immediately to prevent warping or damage.
Image: Premium wooden shelves designed for wine storage.
Fuasgladh thrioblaidean
Mus cuir thu fios gu seirbheis, ath-view an earrann seo airson cùisean cumanta agus fuasglaidhean.
| Trioblaid | Adhbhar a dh’fhaodadh a bhith ann | Fuasgladh |
|---|---|---|
| Chan eil inneal ag obair | No power; circuit breaker tripped; power cord not plugged in. | Thoir sùil air an t-solar cumhachd, ath-shuidhich am briseadair cuairte, dèan cinnteach gu bheil an corda air a phlugaigeadh a-steach gu tèarainte. |
| Chan eil an teòthachd fuar gu leòr | Door not closed properly; excessive door openings; warm items added; poor ventilation; temperature setting too high. | Ensure door is sealed; reduce door openings; allow time for new items to cool; check ventilation; lower temperature setting. |
| Crathadh cus | Appliance not level; unit touching a wall or cabinet. | Adjust leveling feet; ensure adequate clearance around the unit. |
| Fuaim bhon aonad | Normal compressor operation; fan noise; refrigerant flow. | These are normal operating sounds. If noise is unusual or excessive, contact service. |
| Moisture on interior walls | Taiseachd àrd; fosgladh dhorsan tric. | This is normal during high humidity. Reduce door openings. |
Sònrachaidhean
Detailed technical specifications for the KoolMore Reserve KM-CWB24-WPR cooler.
- Ainm a' mhodail: KM-CWB24-WPR
- Meudan an toraidh (D x L x À): 23.4" x 22.6" x 33.9"
- Cuideam nì: 106 Punnd
- Comas: 20 Bottles (Right Zone) + 2.1 Cu. Ft. (Left Zone)
- rèiteachadh: Pannal Deiseil
- Dath: Dubh
- Seòrsa stàlaidh: Air a thogail a-steach
- Àireamh de dhorsan: 2 (French Door)
- Siostam dì-reothadh: fèin-ghluasadach
- Voltage: 115 Volt
- Seòrsa pluga cumhachd: Seòrsa A - 2 phrìne (Ameireaga a Tuath)
- Seòrsa Sgeilp: Glass and Wood
- Àireamh de sgeilpichean: 8
- Modh fuarachaidh: Compressor
- Seòrsa compressor: Scroll rothlach
- Smachd teòthachd a ghabhas atharrachadh: Tha
- Caitheamh lùtha bliadhnail: 171 Kilowatt Uairean sa bhliadhna
- fuarachail: R-134a no R-600a
- Seòrsa glasaidh: iuchair
- Teisteanas: ETL
Fiosrachadh Barantais
This KoolMore Reserve KM-CWB24-WPR cooler comes with a Barantas Pàirtean is Saothair 1-Bliadhna from the date of purchase. This warranty covers defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims. For full terms and conditions, refer to the warranty card included with your product or contact KoolMore customer service.
Taic Luchd-cleachdaidh
If you have any questions, require technical assistance, or need to make a warranty claim, please contact KoolMore customer support. Refer to the contact information provided in your product packaging or visit the official KoolMore weblàrach-lìn airson am fiosrachadh taic as ùire.
